Rename notes to provide a more meaningful label.In the Engineer’s Notebook browser, the program assigns each note a name and lists it in the order in which you created it. Notes can contain links to external files, such as spreadsheets, word-processing documents, graphics, or audio files. Each note consists of a comment box and a view of the model.Įxamples of notes include design strategy, reason for a design decision, manufacturing instructions, or information from a test or FEA calculation. You can attach a note can to an edge, sketch, feature, part, or other selection in the model. You can add comment boxes or more views to a note, or add more notes to the notebook. When you add the first note to a model, the program creates a notebook. To start the Engineers Notebook, select a part in the window, right-click, and click Create Note. Create notes and store them as part of a model.
